Product Features & Details

H-Frame Construction for Stable Pressing

The MDY2000 uses an H-frame structure that positions the pressing cylinder above the worktable. The two upright sections support the upper crossbeam and table, providing a stable arrangement for applying force to the workpiece.

This layout allows tooling and components to be positioned beneath the ram. Workpiece dimensions, support points, and tooling alignment should be reviewed to ensure that the load is applied correctly within the machine’s working area.

Hydraulic Drive with 2,000 kN Nominal Force

The model specification lists a nominal pressing force of 2,000 kN. Hydraulic power moves the ram to apply force through the selected tooling.

This provides a basis for evaluating operations such as component pressing, straightening, and forming. The required force must be assessed alongside the workpiece material, contact area, tooling geometry, and available travel.

Separate Hydraulic Power Unit

The illustrated machine layout uses a hydraulic power unit positioned beside the press. This arrangement separates the motor, pump, and reservoir from the main working area and provides access for routine inspection.

The MDY2000 specification lists a 7.5 kW motor and a 135 L oil tank. Hydraulic connections, oil requirements, and the installation layout should be confirmed for the supplied configuration.

Adjustable Worktable for Different Setups

The specification lists table adjustment as 300 mm × 2. Changing the worktable position allows the working space to be adapted for different tooling and component heights.

A suitable table position helps accommodate the workpiece while preserving the clearance needed for loading, pressing, and removal. The table adjustment method and available positions should be confirmed before ordering.

Simple Operating Controls

The supplier describes improvements intended to add functionality while keeping operation straightforward. The illustrated machines use an accessible control panel positioned beside the frame.

This arrangement places operating controls close to the pressing area for setup and machine operation. The exact control functions and operating modes depend on the confirmed configuration.

Working Speed for Controlled Operations

The MDY2000 specification lists a working speed of 3.9 mm/s. This refers to the stated pressing speed and should be considered when assessing cycle time.

Actual production output also depends on approach and return travel, workpiece loading, tooling changes, and part removal. These requirements should be reviewed when selecting the machine for a production task.

Application-Based Tooling Selection

The press can be evaluated for different operations by selecting appropriate tooling and workpiece supports. Potential applications include pressing components into assemblies, straightening parts, and forming suitable metal workpieces.

For each application, the tooling must match the required force, part geometry, and support arrangement. Providing drawings or sample parts helps establish whether the MDY2000 is suitable for the intended task.

Technical Parameters

Parameter	MDY2000 Specification
Machine type	H-frame hydraulic press
Nominal pressing force	2,000 kN
Motor power	7.5 kW
Oil tank capacity	135 L
Table adjustment, as listed	300 mm × 2
Machine weight	2,480 kg
Working speed	3.9 mm/s
Brand	SMAC

Final specifications and included equipment are subject to the confirmed machine configuration.

Customization Options

Discuss the following requirements with the supplier when requesting a quotation:

• Tooling and workpiece supports: Specify the pressing operation, part geometry, and support requirements.
• Working clearance: Confirm that the table positions and ram travel accommodate the complete tooling setup.
• Electrical supply: Specify the voltage and frequency available at the installation site.
• Operating controls: Confirm the required operating functions and available control options.
• Installation layout: Review the position of the separate hydraulic power unit and the required floor space.

Availability of modifications should be confirmed with the supplier.

FAQ

What is the nominal pressing force of the MDY2000?

The model specification lists 2,000 kN. Machine selection should also account for tooling, workpiece support, and the force required by the intended operation.

Does the machine use a separate hydraulic power unit?

The supplied product images show a hydraulic power unit beside the press. Confirm the final arrangement and connection requirements in the quotation.

Can the worktable be adjusted?

Yes. The MDY2000 specification lists table adjustment as 300 mm × 2. Request the table position drawing and adjustment instructions for the exact configuration.

What applications can be considered?

The machine can be assessed for pressing, straightening, forming, and component assembly tasks. Suitability depends on the material, required force, workpiece dimensions, and tooling.

What information is needed for a quotation?

Provide the part drawing, material, required pressing force, tooling dimensions, expected production volume, and site electrical supply.

What inspection documents are available?

The listing states that a machinery test report and an outgoing inspection video are provided.

What warranty is listed?

The product attributes state a one-year warranty. Coverage and service arrangements should be confirmed in the purchase agreement.

Support & Service

• Inspection documentation: A machinery test report and outgoing inspection video are listed as available.
• Warranty: A one-year warranty is stated, subject to the agreed coverage and terms.
• Application review: Submit workpiece and tooling drawings to discuss machine suitability.
• Installation information: Request foundation, electrical, hydraulic, and space requirements before delivery.
• Operation and maintenance documentation: Request the operating manual, hydraulic oil specification, maintenance schedule, and spare-parts information.

Send your workpiece drawing and pressing requirements to request a confirmed MDY2000 specification and quotation.
