Overview

The Heavy Duty Horizontal CNC Lathe Machine is designed for high-precision and efficient turning of medium to large metal components in demanding industrial production environments.

Combining a rigid horizontal bed structure, powerful spindle system and CNC-controlled feed mechanism, the machine provides stable cutting performance for both rough machining and precision finishing. It is suitable for machining cylindrical parts, shafts, discs, sleeves and other rotational components made from steel, cast iron and non-ferrous metals.The CNC system allows operators to complete multiple turning processes with consistent accuracy and reduced manual intervention. Typical operations include external and internal turning, facing, taper turning, threading, drilling, boring and contour machining.With its combination of high rigidity, machining accuracy and production efficiency, this horizontal CNC lathe is suitable for machine shops, industrial manufacturers and production lines requiring reliable metal turning capability.

---

Key Features

Heavy-Duty Rigid Machine Structure

The robust horizontal bed construction provides excellent rigidity and vibration resistance during heavy cutting operations.The stable machine structure helps maintain machining accuracy when processing large-diameter, long or heavy workpieces.

High-Precision CNC Machining

CNC-controlled X- and Z-axis movement enables accurate positioning and repeatable machining.The machine is suitable for both rough turning and precision finishing, helping manufacturers maintain consistent dimensional accuracy across repeated production cycles.

Powerful Spindle System

A high-torque spindle provides stable cutting performance for a wide range of metal materials.The spindle system is designed to support both heavy material removal and precision turning, making the machine suitable for different machining requirements.

Multiple CNC Control Options

Different CNC control systems can be configured according to production requirements and operator preferences.Available configurations can include systems such as:

• FANUC
• Siemens
• GSK
• Other CNC systems upon request

English-language interfaces can also be configured for international customers.

Efficient Automatic Machining

Once the machining program is set, the CNC lathe can automatically complete multiple turning operations.This helps reduce manual intervention, improve production consistency and increase machining efficiency for batch production.

Flexible Tooling Configuration

Different tool post and turret configurations can be selected depending on the machining process.Options may include multi-station tool posts or automatic turrets to support faster tool changes and multi-process machining.

Wide Workpiece Compatibility

The machine can process various rotational metal components, including:

• Shafts
• Flanges
• Sleeves
• Rollers
• Discs
• Bushings
• Cylindrical components
• Threaded components
• Large industrial machine parts

Customizable Machine Configuration

Machine specifications can be customized according to workpiece size, material and machining requirements.Optional configurations may include different:

• CNC control systems
• Spindle sizes
• Chuck sizes
• Tool turrets
• Tailstocks
• Chip conveyors
• Hydraulic systems
• Machine voltages
• Safety enclosures

---

Technical Specifications

ITEMS	CK6140S
Max. Swing over bed	410mm(16″)
Max. cross travel(X)	300mm
Max. Longitudinal travel (Z)	1000mm
Rapid feed for Axis X	5m/min
Rapid feed for Axis Z	8m/min
Size of tool shank	20×20mm
Min input	0.001mm
Repeatability X/Z	0.0075/0.01mm
	φ150mm(for gang tools)
	230mm



Note: Machine specifications may vary according to model, turning diameter, machining length, CNC system and optional configuration. Please send us your workpiece dimensions, material and drawing for model selection.

---

Applications

The Heavy Duty Horizontal CNC Lathe is designed for a wide range of industrial metalworking applications.

General Machinery Manufacturing

Suitable for machining shafts, sleeves, flanges, rollers, bushings and other rotational components used in industrial machinery.

Automotive Components

Can be used for turning various vehicle and mechanical transmission components requiring stable dimensional accuracy and repeatable production.

Energy Equipment

Suitable for processing shafts, flanges, connecting components and other large rotational parts used in energy-related equipment.

Mining & Heavy Equipment

The rigid machine structure makes the CNC lathe suitable for machining large and heavy-duty parts used in mining machinery and industrial equipment.

Oil & Gas Equipment

Suitable for machining cylindrical components, shafts, sleeves and threaded metal components used in oilfield and related industrial equipment.

Pump & Valve Manufacturing

Can be used for machining valve components, pump shafts, sleeves, flanges and other precision rotational parts.

Industrial Maintenance & Repair

Suitable for workshops that need flexible machining capability for replacement parts, equipment maintenance and custom metal components.

Batch Metal Parts Production

CNC automatic machining makes the machine suitable for manufacturers requiring repeatable production of medium and large metal components.

---

FAQ

1. What materials can this CNC lathe process?

The machine can process a wide range of metallic materials, including carbon steel, alloy steel, stainless steel, cast iron, aluminum and other non-ferrous metals.The actual cutting parameters depend on the workpiece material, cutting tool and machining requirements.

2. How do I choose the correct CNC lathe model?

The most suitable model depends mainly on:

• Maximum workpiece diameter
• Workpiece length
• Workpiece weight
• Material
• Required machining accuracy
• Machining process
• Production volume

You can send us your workpiece drawing, material, dimensions and machining requirements, and our technical team can recommend a suitable configuration.

3. What operations can the machine perform?

Depending on the selected configuration and tooling, the machine can perform operations such as:

• External turning
• Internal turning
• Facing
• Taper turning
• Thread cutting
• Grooving
• Drilling
• Boring
• Contour machining

Different tooling configurations can be selected according to your production requirements.

4. Which CNC control system can I choose?

GSK, FANUC, Siemens and other control system configurations may be available depending on the machine model.We can recommend a suitable CNC system based on your operating habits, local maintenance requirements and budget.

5. Can the machine voltage be customized?

Yes.The electrical configuration can be adapted according to the industrial power supply standards of the destination country.Please provide your required voltage, frequency and phase before production.

6. Can the CNC lathe be customized?

Yes. OEM and ODM services are available.Depending on your application, customization can include machine appearance, CNC controller, chuck, spindle, turret, tailstock, voltage, safety enclosure and other functional configurations.

7. Can you test my workpiece before shipment?

Workpiece drawings or machining requirements can be evaluated before production.Where applicable, machining tests, machine inspection and operation videos can also be provided before shipment so that customers can confirm machine performance.

8. Is this machine suitable for mass production?

Yes.The CNC-controlled machining process provides good repeatability and reduces operator intervention, making the machine suitable for both flexible small-batch production and continuous industrial manufacturing.

---

Support

We provide comprehensive support from machine selection to installation and long-term operation.

Pre-Sales Technical Support

Before ordering, our technical team can help evaluate:

• Workpiece drawings
• Workpiece dimensions
• Material
• Required tolerance
• Machining process
• Production capacity

Based on these requirements, we can recommend an appropriate machine model and configuration.

OEM & ODM

Machine appearance and functional configurations can be customized according to customer requirements.Private labeling and customized machine configurations are also available for distributors and industrial customers.

Quality Inspection

Machines undergo inspection before shipment.Inspection and machine operation videos can be provided to help customers confirm machine condition and functionality before delivery.

Export Packaging

Machines are prepared with professional export packaging suitable for international transportation.Packaging solutions are selected according to machine dimensions, weight and shipping requirements to help protect the equipment during transportation.

Logistics Assistance

We can assist with international shipping arrangements and provide the necessary export documentation according to order requirements.

Installation & Remote Technical Support

English technical guidance and remote commissioning support are available to assist customers with machine installation, setup and operation.

English CNC Interface

English-language CNC interfaces and operating guidance can be provided for international customers.

Warranty

The machine is supplied with a one-year warranty according to the agreed order terms.Technical assistance continues after the warranty period, with long-term technical support available for machine operation and maintenance.

Spare Parts & Technical Service

We can provide technical assistance for machine maintenance, troubleshooting and replacement parts throughout the machine’s service life.

---

Need Help Choosing the Right CNC Lathe?

Every machining application is different.Send us your:

Workpiece Drawing + Material + Maximum Diameter + Maximum Length + Required Accuracy + Production Quantity

Our technical team will help you select the appropriate CNC lathe configuration for your production requirements.

Contact us for machine specifications, configuration options and quotation.
