Overview

The CK6150 Horizontal Flat Bed CNC Lathe Machine is an industrial CNC turning solution designed for manufacturers that require a combination of machining accuracy, structural rigidity and production efficiency.Built around a rigid horizontal flat-bed structure, the CK6150 provides stable support during both heavy material removal and precision finishing. The machine is particularly suitable for machining shaft-type and disc-type metal components, including cylindrical surfaces, conical surfaces, end faces, grooves and different types of threads.Compared with conventional manual lathes, CNC-controlled X- and Z-axis movement enables the machine to perform programmed machining cycles with improved repeatability and reduced operator intervention.The CK6150 series typically provides a 500 mm swing over bed, approximately 7.5 kW spindle motor, and multiple machining-length and spindle-bore configurations. Depending on configuration, spindle bore options can include approximately 82 mm or larger, making the machine suitable for both individual components and bar-type workpieces.Different CNC systems, tool turrets, chucks and tailstock configurations can be selected according to workpiece dimensions, machining processes and production requirements.

Key Features

Rigid Horizontal Flat Bed Design

The heavy-duty flat bed provides excellent structural stability during machining.Its rigid cast structure helps reduce vibration during heavy cutting operations, improving cutting stability and surface finish when processing steel, cast iron and other industrial metals.

High-Precision CNC Control

Servo-controlled X- and Z-axis movement provides accurate positioning and repeatable machining.The CNC system enables operators to program multiple machining processes, helping improve production consistency and reduce dependence on manual operation.

Powerful Spindle for Metal Turning

The CK6150 is equipped with a high-torque spindle system designed for both rough machining and precision finishing.The machine can accommodate a wide range of cutting conditions for different materials and component sizes.

500 mm Swing Over Bed

With a maximum swing over bed of approximately 500 mm, the CK6150 provides sufficient machining capacity for a wide range of medium-sized industrial components.

This makes it suitable for machining:

• Shafts
• Sleeves
• Flanges
• Discs
• Rollers
• Bushings
• Couplings
• Threaded components

Large Spindle Bore Options

Different spindle-bore configurations can be selected according to machining requirements.Common CK6150 configurations use approximately 82 mm spindle bore, while larger-bore options may also be available.A larger spindle bore allows bars, tubes and shafts to pass through the spindle, increasing machining flexibility.

Multiple Machining Length Options

Different distances between centers can be configured for short and long workpieces.

Depending on the selected machine version, commonly available CK6150 machining lengths include approximately:

• 750 mm
• 1000 mm
• 1500 mm
• Longer configurations upon request

This allows customers to choose a machine according to actual workpiece length instead of purchasing unnecessary machine capacity.

Automatic Tool Changing

The machine can be equipped with an electric multi-station tool post or turret.

Typical configurations include:

• 4-station electric turret
• 6-station turret
• Other tooling configurations upon request

Multiple cutting tools can be installed for different operations within one machining cycle.

Flexible CNC System Options

Different CNC control systems can be configured according to customer requirements.

Available options may include:

• GSK
• FANUC
• Siemens
• KND
• Other CNC systems upon request

English-language CNC interfaces can be provided for international customers.

Precision Ball Screw Feed System

The X- and Z-axis feed system uses precision ball screws driven by servo motors.This provides stable feed movement and improves positioning accuracy during automated machining.

Hardened Guideways

The machine guideways are hardened and precision ground to improve wear resistance and maintain machining accuracy during long-term industrial operation.

Flexible Chuck Configuration

Different workholding systems can be selected according to workpiece type and automation requirements.

Options may include:

• Manual 3-jaw chuck
• Hydraulic chuck
• Larger-diameter chuck
• Custom workholding solutions

Tailstock Support for Long Workpieces

The tailstock provides additional support when machining long shafts and other elongated components.Manual or hydraulic configurations can be selected according to machine configuration and production requirements.

Technical Specifications

Parameter	Specification
Model	CK6150
Machine Type	CNC Lathe Machine
Structure	Horizontal Flat Bed
Control Type	CNC
Automatic Grade	Automatic
Number of Axes	2 Axis
Max. Swing Over Bed	Approx. 500 mm
Max. Swing Over Cross Slide	Approx. 250–300 mm, depending on configuration
Machining Length	750 / 1000 / 1500 mm or customized
Spindle Bore	Approx. 82 mm / optional larger bore
Spindle Speed	Variable, according to configuration
Main Spindle Motor	Approx. 7.5 kW
X-Axis Drive	Servo Motor
Z-Axis Drive	Servo Motor
Tool Post / Turret	4 / 6 Station or Optional
Chuck Type	Manual / Hydraulic
Tailstock	Manual / Hydraulic Optional
CNC Controller	GSK / FANUC / Siemens / KND / Optional
Processing Precision	High-Precision CNC Turning
Suitable Materials	Steel, Stainless Steel, Cast Iron, Aluminum, Copper and Other Metals
Power Supply	Customized for Destination Country
Machine Condition	New
OEM / ODM	Available

Published CK6150 configurations consistently identify the machine as a horizontal flat-bed automatic CNC lathe with approximately 500 mm swing over bed and 7.5 kW spindle power. Exact spindle speed, spindle bore, machining length and turret configuration can vary between machine configurations.

Note: Final technical specifications should be confirmed according to workpiece dimensions, machining requirements and selected machine configuration.

Applications

The CK6150 CNC Lathe Machine is suitable for precision and batch machining across a wide range of industrial sectors.

Shaft Machining

Suitable for machining:

• Drive shafts
• Motor shafts
• Pump shafts
• Transmission shafts
• Machine shafts
• Axles

The tailstock provides additional support for longer workpieces.

Disc and Flange Components

The machine can process different disc-type components including:

• Flanges
• Pulleys
• Hubs
• Couplings
• Circular plates
• Machine discs

General Machinery Manufacturing

The CK6150 can be used to manufacture:

• Bushings
• Sleeves
• Rollers
• Pins
• Couplings
• Spacers
• Threaded components
• Precision machine parts

Automotive Parts Manufacturing

Suitable for repetitive CNC turning of automotive and transportation components requiring consistent dimensional accuracy.Typical workpieces can include shafts, hubs, sleeves, couplings and other rotational components.

Pump & Valve Manufacturing

The machine can be used for producing:

• Pump shafts
• Valve stems
• Flanges
• Sleeves
• Bushings
• Threaded components

Agricultural Machinery

Suitable for machining shafts, rollers, bushings, axles, couplings and replacement parts used in agricultural equipment.

Heavy Machinery & Industrial Equipment

The rigid flat-bed structure makes the CK6150 suitable for components used in:

• Industrial machinery
• Mining equipment
• Construction machinery
• Production equipment
• Mechanical transmission systems

Maintenance & Repair Workshops

The programmable CNC system also makes the machine suitable for workshops producing replacement parts and customized components.Stored machining programs can be reused for repeated repair and production jobs.

Batch Production

Compared with conventional manual lathes, CNC automation improves repeatability and reduces operator intervention.

The CK6150 is therefore suitable for:

• Small-batch production
• Medium-volume production
• Repetitive component machining
• Industrial production lines

Machining Capabilities

Depending on tooling and machine configuration, the CK6150 can perform:

• External cylindrical turning
• Internal turning
• Facing
• Taper turning
• Arc machining
• Grooving
• Chamfering
• Thread cutting
• Drilling
• Boring
• Finishing
• Rough turning

This allows multiple machining processes to be completed on one CNC lathe.

FAQ

1. What is the CK6150 CNC lathe used for?

The CK6150 is mainly used for CNC turning of shaft-type and disc-type metal components.It can perform external turning, internal turning, facing, taper turning, grooving, threading, drilling and boring.

2. What is the maximum turning diameter?

The CK6150 typically provides a maximum swing over bed of approximately 500 mm.Actual maximum machining diameter depends on the tooling, chuck and selected machine configuration.

3. What workpiece lengths are available?

Different machine-bed lengths can be selected.

Common configurations include approximately:

• 750 mm
• 1000 mm
• 1500 mm

Longer configurations may also be available depending on production requirements.

4. What materials can the CK6150 process?

The machine can process a wide range of metals including:

• Carbon steel
• Alloy steel
• Stainless steel
• Cast iron
• Aluminum
• Copper
• Other non-ferrous metals

Cutting speed, feed rate and tooling should be selected according to the workpiece material.

5. Is the CK6150 suitable for heavy cutting?

Yes.The horizontal flat-bed structure provides good rigidity and stability, making the machine suitable for both rough turning and precision finishing.Actual heavy-cutting capability depends on spindle power, tooling, workpiece size and machine configuration.

6. What is the spindle bore?

Common CK6150 configurations use an approximately 82 mm spindle bore, while larger spindle-bore configurations may be available depending on machine design.If you need to machine bar stock or tubing, please provide the maximum bar diameter when requesting a quotation.

7. Which CNC controller can I choose?

Different CNC systems can be configured according to customer requirements, including:

• GSK
• FANUC
• Siemens
• KND

The final controller can be selected according to operator experience, local service availability and budget.

8. Can I choose a hydraulic chuck?

Yes.Both manual and hydraulic chuck configurations can be provided depending on the machine setup.A hydraulic chuck is particularly suitable for customers requiring faster clamping and higher production efficiency.

9. Can I choose a different tool turret?

Yes.Different tool post and turret configurations can be selected, including 4-station and 6-station systems.The appropriate configuration depends on the number of machining operations required for each workpiece.

10. Is the CK6150 suitable for batch production?

Yes.CNC programming allows repeated machining cycles to be completed with consistent positioning and machining parameters.This makes the CK6150 suitable for repetitive small- and medium-batch production.

11. Can the machine voltage be customized?

Yes.The electrical system can be configured according to the industrial power standards of the destination country.

Please provide:

• Voltage
• Frequency
• Phase

before production.

12. Can the machine be customized?

Yes.OEM and ODM services are available.

Customizable options can include:

• CNC system
• Spindle bore
• Chuck
• Tool turret
• Tailstock
• Machine voltage
• Machine enclosure
• Chip conveyor
• Cooling system
• Machine color
• Logo and nameplate

13. How do I choose the correct CK6150 configuration?

Please provide:

Workpiece Drawing + Material + Maximum Diameter + Maximum Length + Required Accuracy + Production Quantity

Our technical team can evaluate the machining requirements and recommend the appropriate configuration.

Support

We provide complete technical and service support throughout the machine purchasing and operating process.

Pre-Sales Machine Selection

Our technical team can evaluate your workpiece and production requirements before purchase.

Please provide:

• Workpiece drawing
• Workpiece material
• Maximum diameter
• Maximum length
• Machining process
• Required tolerance
• Production quantity

We will recommend the appropriate machine configuration based on your application.

OEM & ODM Service

Machine appearance and functional configurations can be customized according to customer requirements.

We support:

• Machine configuration customization
• Private labeling
• Logo customization
• Functional customization
• CNC controller selection

Quality Inspection Before Shipment

Each machine undergoes inspection before shipment.Complete machine inspection and operating videos can be provided to help customers verify machine condition and operation before delivery.

Professional Export Packaging

Professional export packaging is provided for international transportation.Packaging is selected according to machine dimensions, weight and shipping method to help protect the equipment during long-distance transportation.

International Logistics Assistance

We can assist customers with:

• Export documentation
• International shipping coordination
• Port delivery
• Logistics communication

Remote Installation & Commissioning

English-language technical guidance and remote commissioning support are available.

Our technical team can assist with machine:

• Installation
• Electrical connection
• CNC setup
• Parameter setting
• Trial operation
• Troubleshooting

English CNC Interface

English-language CNC interfaces and technical documentation can be provided for international customers.

One-Year Warranty

The machine is supplied with a one-year warranty according to the agreed order terms.

Lifetime Technical Support

Long-term technical support is available for machine operation, maintenance and troubleshooting after the warranty period.

Spare Parts Support

Replacement parts and technical assistance can be provided throughout the machine’s service life.

Looking for the Right CNC Lathe for Your Parts?

Send us your:

Workpiece Drawing + Material + Maximum Diameter + Maximum Length + Required Accuracy + Production Quantity + Voltage

Our technical team will help you select the appropriate CK6150 CNC Lathe Machine configuration for your production requirements.

Contact us for complete technical specifications, optional configurations and quotation.
